AIHE

Turning insert

TNMG160404-MA(HRC 20~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.4mm
  • Coating:TiALN PVD
TNMG160404-MA-20-45-30-45下载

Turning insert

TNMG160404-MA(HRC 30~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.4mm
  • Coating:TiAlSiN PVD
TNMG160404-MA-20-45-30-45下载

Turning insert

TNMG160404-MA(HRC 44~55)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.4mm
  • Coating:TiAlSiN PVD
TNMG160404-MA -44-55-30-50下载

Turning insert

TNMG160404-MA(HRC 30~50)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.4mm
  • Coating:TiAlSiN PVD
TNMG160404-MA -44-55-30-50下载

Turning insert

TNMG160412-MA(HRC 30~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:1.2mm
  • Coating:TiALSiN PVD
TNMG160404-MS-12-MA下载

Turning insert

TNMG160404-MS(HRC 30~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.4mm
  • Coating:TiAlSiN PVD
TNMG160404-MS-12-MA下载

Turning insert

TNMG160408-MS(HRC 30~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.8mm
  • Coating:TiAlSiN PVD
TNMG160412&08-MS下载

Turning insert

TNMG160412-MA(HRC30~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:1.2mm
  • Coating:TiAlSiN PVD
TNMG160412&08-MS下载

Turning insert

TNMG160408-MA(HRC 20~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.8mm
  • Coating:TiALN PVD
TNMG160408-MA-20-45-30-45下载

Turning insert

TNMG160408-MA(HRC 30~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.8mm
  • Coating:TiAlSiN PVD
TNMG160408-MA-20-45-30-45下载

Turning insert

TNMG160408-MA(HRC 44~55)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.8mm
  • Coating:TiAlSiN PVD
TNMG160408-MA-44-55-20-45下载

Turning insert

TNMG160408-MA(HRC 20~45)

  • Triangular shape
  • Tolerance：M
  • Clearance angle:0°
  • Nominal inscribed circle diameter:16mm
  • Nominal thickness:4.76mm
  • Nose radius:0.8mm
  • Coating:TiAlSiN PVD
TNMG160408-MA-44-55-20-45下载
